Parent Layer: Contours

Sub Layers:

• Default

Name: Contours

Display Field: TextString

Type: Annotation Layer

Geometry Type: esriGeometryPolygon

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>Stormwater system for the City of La Mesa.</SPAN></P><P><SPAN>This feature class contains annotation for topographic contours within the City of La Mesa. The contours were derived from LIDAR data. This annotation is at 10 ft intervals, and has been placed for the stormwater mapbook.</SPAN></P><P><SPAN>Based on the Esri Simplified Stormwater file geodatabase model; added La Mesa content.</SPAN></P></DIV></DIV></DIV>

Copyright Text: City of La Mesa, Department of Public Works

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: false

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 6314617.981860697
YMin: 1851452.6776566058
XMax: 6336727.893349439
YMax: 1870259.0954242647
Spatial Reference: 102646  (2230)

Drawing Info:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• FeatureID ( type: esriFieldTypeInteger, alias: FeatureID )
• ZOrder ( type: esriFieldTypeInteger, alias: ZOrder )
• AnnotationClassID ( type: esriFieldTypeInteger, alias: AnnotationClassID )
• Element ( type: esriFieldTypeBlob, alias: Element )
• SymbolID ( type: esriFieldTypeInteger, alias: SymbolID )
• Status ( type: esriFieldTypeSmallInteger, alias: Status , Coded Values: [0: Placed] , [1: Unplaced] )
• TextString ( type: esriFieldTypeString, alias: TextString, length: 255 )
• FontName ( type: esriFieldTypeString, alias: FontName, length: 255 )
• FontSize ( type: esriFieldTypeDouble, alias: FontSize )
• Bold ( type: esriFieldTypeSmallInteger, alias: Bold , Coded Values: [1: Yes] , [0: No] )
• Italic ( type: esriFieldTypeSmallInteger, alias: Italic , Coded Values: [1: Yes] , [0: No] )
• Underline ( type: esriFieldTypeSmallInteger, alias: Underline , Coded Values: [1: Yes] , [0: No] )
• VerticalAlignment ( type: esriFieldTypeSmallInteger, alias: VerticalAlignment , Coded Values: [0: Top] , [1: Center] , [2: Baseline] , ...1 more... )
• HorizontalAlignment ( type: esriFieldTypeSmallInteger, alias: HorizontalAlignment , Coded Values: [0: Left] , [1: Center] , [2: Right] , ...1 more... )
• XOffset ( type: esriFieldTypeDouble, alias: XOffset )
• YOffset ( type: esriFieldTypeDouble, alias: YOffset )
• Angle ( type: esriFieldTypeDouble, alias: Angle )
• FontLeading ( type: esriFieldTypeDouble, alias: FontLeading )
• WordSpacing ( type: esriFieldTypeDouble, alias: WordSpacing )
• CharacterWidth ( type: esriFieldTypeDouble, alias: CharacterWidth )
• CharacterSpacing ( type: esriFieldTypeDouble, alias: CharacterSpacing )
• FlipAngle ( type: esriFieldTypeDouble, alias: FlipAngle )
• Override ( type: esriFieldTypeInteger, alias: Override )
• SHAPE_Length ( type: esriFieldTypeDouble, alias: SHAPE_Length )
• SHAPE_Area ( type: esriFieldTypeDouble, alias: SHAPE_Area )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
